THERMAL OVERLOAD 5.5-8.0A CL10A
Ideal Part:
SCDLRD12
Mfr Number:
LRD12
Barcode:
3389110346800
Please LogIn
To view pricing, availability and special offers, click the button below and login.
This item is obsolete and no longer available for purchase.
Supplier Packages :
Package options may not always be available
Package Options
Number of items
1 Carton
384 EAC
1 Pack
24 EAC
EAC
Min: 1 EAC
Technical Documents
Technical Documents
Brochure
Product Details
Product Details
TeSys LRD thermal overload relay - 8A/690V - thermal setting range 5 5 - 8A - tripping class 10A - for protection of 3 - phase motors 3kW 400V Differential device with phase failure and load unbalance detection It provides a
TeSys LRD thermal overload relay, 8A/690V, thermal setting range 5.5-8A, tripping class 10A, for protection of 3-phase motors 3kW@400V. Differential device with phase failure and load unbalance detection. It provides a thermal adjustement dial, a manual-automatic reset selector, a test selector for simulation of a tripping, reset and stop buttons, a flag indicator and 2 auxiliary contacts 1NO+1NC for fault signalling. Settings are protected by a transparent cover lockable by sealing. Connection by screw clamp terminals, it connects directly to the bottom terminals of 3-pole contactors LC1D09-D38. Mounting on DIN rail or screw fixing, separated from the contactor, with use of a terminal block LAD7B106 (to be ordered separately). Multi standards certified (IEC, UL, CSA, CCC, EAC, ATEX, Marine), Green Premium compliant (RoHs/Reach).
TeSys LRD thermal overload relay, 8A/690V, thermal setting range 5.5-8A, tripping class 10A, for protection of 3-phase motors 3kW@400V. Differential device with phase failure and load unbalance detection. It provides a thermal adjustement dial, a manual-automatic reset selector, a test selector for simulation of a tripping, reset and stop buttons, a flag indicator and 2 auxiliary contacts 1NO+1NC for fault signalling. Settings are protected by a transparent cover lockable by sealing. Connection by screw clamp terminals, it connects directly to the bottom terminals of 3-pole contactors LC1D09-D38. Mounting on DIN rail or screw fixing, separated from the contactor, with use of a terminal block LAD7B106 (to be ordered separately). Multi standards certified (IEC, UL, CSA, CCC, EAC, ATEX, Marine), Green Premium compliant (RoHs/Reach).
Technical Specifications
Technical Specifications
Thermal overload relay | |
| Adjustable current range | 5.5 |
|---|---|
| Max. rated operation voltage Ue | 690 V |
| Mounting method | Direct attachment |
| Type of electrical connection of main circuit | Screw connection |
| Number of auxiliary contacts as normally closed contact | 1 |
| Number of auxiliary contacts as normally open contact | 1 |
| Number of auxiliary contacts as change-over contact | 0 |
| Release class | CLASS 10 A |
|---|---|
| Reset function input | No |
| Reset function automatic | Yes |
| Reset function push-button | Yes |
| Contacts | 2 x N/O, 2 x N/C |
| Suitable for | D09-D38 |
| Number of poles (total) | 3 |
